| Place of Origin | CHINA |
|---|---|
| Brand Name | HAROK |
| Model Number | VKM1 |
| Minimum Order Quantity | 1000PCS |
| Payment Terms | L/C, T/T, Western Union, MoneyGram |
| Product Name | Molded Case Circuit Breakers | Model | VKM1 |
|---|---|---|---|
| Pole | 2, 3, 4 | Frame Current Inm (A) | 63, 125, 250, 400, 630, 800 |
| Rated Working Voltage Ue (V) | AC415, AC690 | Rated Impulse Withstand Voltage Uimp (V) | 6000, 8000 |
| High Light | AC415 mccb circuit breakers,AC415V Molded Case Circuit Breakers,630A Molded Case Circuit Breakers | ||
VKM1 series
Molded Case Circuit Breakers
1. Application
VKM1 series of molded case circuit breakers are applied to frequently changeover the circuit of rated insulation voltage of 800V (VKM1-63 is 500V), AC 50/60Hz, rated voltage 690V or below (VKM1-63 is 415V), rated operating current 1250A, or start the motor not frequently (VKM1-800 without motor protection). The breakers provided with overload short-circuit and under-voltage protection function to protect the lines and power equipment from damage.
The product can be mounted vertically or horizontally.
2. Technical parameters
| Model | VKM1-63 | VKM1-125 | VKM1-250 | VKM1-400 | VKM1-630 | VKM1-800 | |||||||||||
| Frame current Inm (A) | 63 | 125 | 250 | 400 | 630 | 800 | |||||||||||
| Rated current In (A) | (6),10 16,20 25,32 40,50 63 | (10),16,20 25,32,40 50,63,80 125 | 125,140 160,180 200,225 250 | 250,315 350,400 | 400,500,630 | 630,700 800 | |||||||||||
| Number of poles | 3 | 4 | 2 | 3 | 4 | 2 | 3 | 4 | 2 | 3 | 4 | 2 | 3 | 4 | 3 | 4 | |
| Rated insulation voltage Ui (V) | AC500 | AC800 | |||||||||||||||
| Rated working voltage Ue (V) | AC415 | AC415,AC690 | |||||||||||||||
| Rated impulse withstand voltage Uimp (V) | 6000 | 8000 | |||||||||||||||
| Arcing distance (mm) | 50 | 100 | |||||||||||||||
| Breaking capacity grade | L | M | L | M | H | L | M | H | L | M | H | L | M | H | M | H | |
| Limit short-circuit breaking capacity Icu (kA) | AC415V | 25 | 50 | 35 | 50 | 85 | 35 | 50 | 85 | 50 | 65 | 100 | 50 | 65 | 100 | 75 | 100 |
| Running short-circuit breaking capacity Ics (kA) | AC415V | 18 | 35 | 22 | 35 | 50 | 22 | 35 | 50 | 35 | 42 | 65 | 35 | 42 | 65 | 50 | 65 |
| Operation characteristics (times) | ON | 6000 | 3000 | 2000 | 1500 | 1000 | |||||||||||
| OFF | 8500 | 7000 | 4000 | 4000 | 2500 | ||||||||||||
| total | 14500 | 10000 | 6000 | 5500 | 3500 | ||||||||||||
3. Outline and installation dimensions (mm)
| Model | Pole No. | Outline Dimension (mm) | Installation Dimension (mm) | |||||||
| L1 | L2 | L3 | L4 | a | b | d | H | H1 | ||
| VKM1-63L | 3 | 76 | 135 | 89 | 75 | 25 | 117 | Φ3.5 | 23 | 71 |
| VKM1-63M | 3 | 76 | 135 | 97 | 82 | 25 | 117 | Φ3.5 | 23 | 71 |
| 4 | 100 | 135 | 97 | 82 | 50 | 117 | Φ3.5 | 23 | 71 | |
| VKM1-125L | 2 | 65 | 150 | 89 | 67 | / | 129 | Φ4.5 | 26 | 68 |
| 3 | 92 | 150 | 89 | 67 | 30 | 129 | Φ4.5 | 26 | 68 | |
| 4 | 120 | 150 | 89 | 67 | 60 | 129 | Φ4.5 | 26 | 68 | |
| VKM1-125M | 2 | 65 | 150 | 105 | 85 | / | 129 | Φ4.5 | 26 | 68 |
| 3 | 92 | 150 | 105 | 85 | 30 | 129 | Φ4.5 | 26 | 68 | |
| 4 | 120 | 150 | 105 | 85 | 60 | 129 | Φ4.5 | 26 | 68 | |
| VKM1-125H | 2 | 75 | 150 | 105 | 85 | / | 129 | Φ4.5 | 26 | 68 |
| 3 | 106 | 150 | 105 | 85 | 30 | 129 | Φ4.5 | 26 | 68 | |
| 4 | 140 | 150 | 105 | 85 | 60 | 129 | Φ4.5 | 26 | 68 | |
| VKM1-250L | 2 | 75 | 165 | 110 | 85.5 | / | 126 | Φ4.5 | 30 | 74 |
| 3 | 106 | 165 | 110 | 85.5 | 35 | 126 | Φ4.5 | 30 | 74 | |
| 4 | 140 | 165 | 110 | 85.5 | 70 | 126 | Φ4.5 | 30 | 74 | |
| VKM1-250M | 2 | 75 | 165 | 125 | 104 | / | 126 | Φ4.5 | 30 | 74 |
| 3 | 106 | 165 | 125 | 104 | 35 | 126 | Φ4.5 | 30 | 74 | |
| 4 | 140 | 165 | 125 | 104 | 70 | 126 | Φ4.5 | 30 | 74 | |
| VKM1-250H | 2 | 75 | 165 | 125 | 104 | / | 126 | Φ4.5 | 30 | 74 |
| 3 | 106 | 165 | 125 | 104 | 35 | 126 | Φ4.5 | 30 | 74 | |
| 4 | 140 | 165 | 125 | 104 | 70 | 126 | Φ4.5 | 30 | 74 | |
| VKM1-400L | 3 | 150 | 257 | 151 | 103 | 44 | 194 | Φ7 | 63 | 128 |
| 4 | 198 | 257 | 151 | 103 | 95 | 194 | Φ7 | 65 | 89 | |
| VKM1-400M | 3 | 150 | 257 | 151 | 103 | 44 | 194 | Φ7 | 63 | 128 |
| 4 | 198 | 257 | 151 | 103 | 95 | 194 | Φ7 | 65 | 89 | |
| VKM1-400H | 3 | 150 | 257 | 151 | 103 | 44 | 194 | Φ7 | 63 | 128 |
| 4 | 198 | 257 | 151 | 103 | 95 | 194 | Φ7 | 65 | 89 | |
| VKM1-630L | 3 | 182 | 270 | 155 | 110 | 58 | 200 | Φ7 | 62.5 | 134 |
| 4 | 240 | 270 | 155 | 110 | 116 | 200 | Φ7 | 65 | 89 | |
| VKM1-630M | 3 | 182 | 270 | 155 | 110 | 58 | 200 | Φ7 | 62.5 | 134 |
| 4 | 240 | 270 | 155 | 110 | 116 | 200 | Φ7 | 65 | 89 | |
| VKM1-630H | 3 | 182 | 270 | 155 | 110 | 58 | 200 | Φ7 | 62.5 | 134 |
| 4 | 240 | 270 | 155 | 110 | 116 | 200 | Φ7 | 65 | 89 | |
| VKM1-800L | 3 | 210 | 280 | 150 | 108 | 70 | 243 | Φ7 | 65.5 | 105 |
| 4 | 280 | 280 | 150 | 108 | 70 | 243 | Φ7 | 65.5 | 105 | |
| VKM1-800M | 3 | 210 | 280 | 150 | 108 | 70 | 243 | Φ7 | 65.5 | 105 |
| 4 | 280 | 280 | 150 | 108 | 70 | 243 | Φ7 | 65.5 | 105 | |
| VKM1-800H | 3 | 210 | 280 | 150 | 108 | 70 | 243 | Φ7 | 65.5 | 105 |
| 4 | 280 | 280 | 150 | 108 | 70 | 243 | Φ7 | 65.5 | 105 | |
