Place of Origin | CHINA |
Brand Name | HAROK |
Model Number | GFAD-1 |
PRODUCT DETAILS
Product Name | GFCI ADAPTOR |
High Light | 125Vac GFCI Adaptor , UL GFCI Adaptor |
PRODUCT DESCRIPTION
When the leakage current in the circuit or load equipment or the ground neutral fault reaches to the 4~6mA, the GFCI plug can break the circuit automatically within 0.025 Seconds (25ms)
GFCI features surge protection and lightning protection function withstanding 6 kilovolts test. Performed 6000+ times factory tests, which is twice the testing times of UL standard
Provided with the functions of auto-monitoring, waterproof, surge withstanding, dustproof, weather-resistance, operating supply indication and the like
Reset Type: Manual Reset
Rated Voltage: 125Vac
Rated Current: GFCI 15A
Rated Frequency: 60Hz
Rated Residual Operating Current: 4mA～6mA
Action Time for the Residual Current: T=(20/I)1.43mS (6mA,≤1s；264mA,≤25ms)
Voltage Surge Withstand: 6KV/3KA
Operating Temperature Range: -35℃～+66℃
Technical Details
Manufacturer | ELEGRP |
Item Weight | 1.76 ounces |
Package Dimensions | 6 x 3 x 3 inches |
Color | Yellow |
Style | Manual Reset |
Voltage | 125 Volts |
Plug Format | A- US style |
Certification | UL |
Batteries Included? | No |
Batteries Required? | No |
